Main Data
| ITEM | UNIT | LGD-4-2LR | LGD-2-2LR |
Number of cavity | Cavity | 4 | 2 |
Theoretical Output | Pcs/h | 2000-2200 | 1000-1200 |
Max.container volume | L | 2 | 2 |
| Max.neck diameter | mm | 45 | 45 |
| Max.container diameter | mm | 115 | 115 |
Max.container height | mm | 330 | 360 |
Mould Thickness | mm | 210 | 240 |
Mould Stroke | mm | 130 | 130 |
Stretching Stroke | mm | 120 | 120 |
Power of Main Blower | KW | 44 | 30 |
Actual power consumption | KW | 25-30kw | 12-18kw |
Working Pressure | Mpa | 0.8 | 0.8 |
Blowing pressure | Mpa | ≦3.5 | ≦4.0 |
Measurement of Main Blower | mm | 4700x2150x2100 | 3700x1700x2100 |
Measurement of Elevator | mm | 1960x1460x2550 | 1960x1460x2550 |
Weight of Main Blower | kg | 5000 | 2800 |
Configuration Table of Automatic Bottle Blower
| Part name | Specifications | Place of Origin |
Shift servo motor | DELTA | Taiwan |
Clamping cylinder | SMC | Japan |
Stretching cylinder | SMC | Japan |
Manipulator | Mindman | Taiwan |
Overturn cylinder | SMC | Japan |
Blanking cylinder | SMC | Japan |
Bottle taking forward and backward cylinder | SMC | Japan |
Lif cylinder for taking blank and bottle | SMC | Japan |
Operating valve | SMC | Japan |
Blowing valve | Parker | U.S.A |
Guide | HIWIN | Taiwan |
PLC control | DELTA | Taiwan |
Screen | DELTA | Taiwan |
Circuit breaker | SCHNEIDER | France |
Relay | OMRON | Japan |
Photoelectric switch | OMRON | Japan |
Heater | Self-rotating infrared heating is built into the host | |
