Main Data
| ITEM | UNIT | LGG-4-750 | LGG-4-15 | LGG-6-750 | LGG-6-15 |
Number of cavity | Cavity | 4 | 4 | 6 | 6 |
Theoretical Output | Pcs/h | 6500-7000 | 5500-6000 | 8500-9000 | 7000-7500 |
Max.container volume | L | 0.75 | 1.5 | 0.75 | 1.5 |
| Max.neck diameter | mm | 45 | 45 | 45 | 45 |
| Max.container diameter | mm | 75 | 95 | 75 | 95 |
Max.container height | mm | 260 | 330 | 260 | 330 |
Mould Thickness | mm | 210 | 210 | 210 | 210 |
Mould Stroke | mm | 100 | 130 | 100 | 130 |
Stretching Stroke | mm | 80 | 100 | 80 | 100 |
Power of Main Blower | KW | 58 | 58 | 86 | 86 |
Actual power consumption | KW | 20-25kw | 30-35kw | 35-40kw | 40-45kw |
Working Pressure | Mpa | 0.8 | 0.8 | 0.8 | 0.8 |
Blowing pressure | Mpa | ≦3.5 | ≦3.5 | ≦3.5 | ≦3.5 |
Measurement of Main Blower | mm | 3700x2100x2100 | 4500x2100x2100 | 5000x2100x2100 | 5800x2100x2100 |
Measurement of Elevator | mm | 1960x1460x2550 | 1960x1460x2550 | 1960x1460x2550 | 1960x1460x2550 |
Weight of Main Blower | kg | 5000 | 5500 | 6000 | 6600 |
Configuration Table of Full Servo Bottle Blower
| Part name | Specifications | Place of Origin |
Shift servo motor | DELTA | Taiwan |
Clamping servo motor | DELTA | Taiwan |
Tension servo motor | DELTA | Taiwan |
Manipulator | MINDMAN | Taiwan |
Overturn cylinder | SMC | Japan |
Blanking cylinder | SMC | Japan |
Bottle taking forward and backward cylinder | SMC | Japan |
Lif cylinder for taking blank and bottle | SMC | Japan |
Operating valve | SMC | Japan |
Blowing valve | Parker | U.S.A |
Guide | HIWIN | Taiwan |
PLC control | DELTA | Taiwan |
Screen | DELTA | Taiwan |
Circuit breaker | SCHNEIDER | France |
Relay | OMRON | Japan |
Photoelectric switch | OMRON | Japan |
Heater | Self-rotating infrared heating is built into the host | |
